产品介绍Description
■采用全液压转向，机动灵活。
■65型三元件液力变矩器，定轴式动力换挡变速箱，实现无级变速，操纵灵活，提高了作业效率。
■工作装置具有自动放平功能，效率高且能减轻驾驶人员的操作强度。
■It adopts entire-hydraulic steering and its operation is flexible.
■Adopt three compents of torque converter and counter shaft power shift,the machine can achieve continuously variable transmission, flexible operation, and high efficiency.
■The working equipment has an automatic leveling function and high efficiency,which is able to lighten the driver’s operation intensity.
技术参数（Specification）
|
铲斗容量m3 |
Bucket capacity (m3 ) |
0.8 |
|
额定载重量 t |
Rated load (t) |
1.5 |
|
机重 t |
Weight (t) |
4.4 |
|
动臂提升时间s |
Lifting time of the arms (s) |
≤6 |
|
三项和s |
The sum of three items(s) |
≤10 |
|
行走速度km/h |
Traveling speed (km/h) |
0-18 |
|
前进一档 |
Forward gear I |
0-8 |
|
前进二档 |
Forward gear II |
0-18 |
|
倒档 |
Reverse gear |
I 0-8 II 0-18 |
|
最大爬坡 |
Max. climbing gradient |
30o |
|
总长mm |
Overall length (mm) |
5500 |
|
总宽mm |
Overall width(mm) |
1900 |
|
总高mm |
Overall height(mm) |
2850 |
|
轴距mm |
Wheel base (mm) |
2200 |
|
轮距mm |
Wheel tread(mm) |
1450 |
|
最大卸载高度mm |
Max. dumping height(mm) |
2800/3200 |
|
卸载距离mm |
Dumping reach (mm) |
860 |
|
发动机型号 |
Engine model |
4100/490增压 |
|
额定功率kw |
Rated power(kw) |
45/48 |
|
额定转速r/min |
Rated speed(r/min) |
2400 |
|
轮胎规格 |
Tire type |
17.5-16 |
